yka2235 is a six-axis full functional machine for dry/wet cutting, which is designed for high-precision and high-efficiency cutting of spiral bevel gears and hypoid gears.under normal processing conditions, the cutting precision reaches level 5, specified in standard
machine features:
1、vertical gantry structrue, with stable and reliable perfomance and high degree of processing accuracy;
2、high-rigid motorized spindle with direct-drive high torque motors;
3、dry cutting with high-effciency,environmentally-friendly and energy-saving, lower cost of processing.
4、auotmatic loading, perpheral machine is neat and clear.
function configurations:
1、including facehobbing and facemilling;
2、high-speed dry cutting;
3、including hcs hypoid cutting control software;
4、full closed-loop control,and all axes with high-precision encoders,workpiece spindle with high-precision angel encoder;
5、workholding system with disc spring for hydraulic clamping to relex, and clamping measurement;
6、including acutomatic stock divider;
7、alam with help system;
8、safe protection control module (including esr, emergency withdraw,current protection and temperature protection );
9、automatic loading (option).
specification | value | |
cutter size | face milling | φ(2.7～9)＂ |
| face hobbing | r(39～105）mm | |
workpiece parameters | max. transmission ratio | （10:1） |
max.transverse module(mm) | 10 | |
range of tooth numbers | 5～200 | |
max.pitch diameter(mm) | 350 | |
spindle taper outside diameter(mm) | φ128.1906 | |
workpiece spindle taper | （1:18.2857） | |
reducing sleeve 1 taper bore, outside diameter and taper | φ99.2187mm （1:19.6923） | |
tool spindle nose taper, outside diameter and taper | φ58.221mm (1:24) | |
machine dimension ( including guards) | l(mm) | 4500 |
w(mm) | 4000 | |
h(mm) | 3300 | |
gross power(kw) | 100 | |
net weight(kg) | 26500 | |
floor space(mm2) | 4500×5500 | |
